Automatic 8-Layer 3000L Water Tank Blow Moulding Machine

Name: Automatic 8Layer 3000L Water Tank Blow Moulding Machine
Brand: HUAYU
Price: 440000 USD

Quality Automatic 8-Layer 3000L Water Tank Blow Moulding Machine for sale

Brand Name : HUAYU

Model Number : HYBM3000-8

Certification : ISO9001, CE

Place of Origin : CHINA

MOQ : 1SET

Price : 440000 USD

Payment Terms : L/C,T/T

Supply Ability : 1 SET 120DAYS

Delivery Time : 4 MONTHS

Packaging Details : be disassembled into many parts for container transportation

Cooling System : Water Cooling

Automation Grade : Automatic

System : Touch screen

Mould Cavity : Single/Double

Clamping Force : 200T

Advantages : 20 Years Experiences

Machine Size : 5.0x2.5x2.95M

Air Seat Stroke : 400mm

Color : Customied

Showroom Location : None

Mould Material : Aluminum

Applicable Material : HMWHDPE

Power Source : Electric

Product Range : Plastic Jerrycan, Drum

Machine Dimension : 8.5*6*7.2

Contact Now

The HUAYU3000L-8L Blow Moulding Machine combines cutting-edge technology with a user-friendly interface. Its high-speed production and energy-saving features make it perfect for industrial applications, delivering high output with consistent product quality and uniform wall thickness.

Extrusion System
Screw diameter	90mm2 ,100mm4	Nitrided 38CrMoAIA
Screw L/D ratio	28:1	special designed screw can ensure the material plasticizing uniform and efficient
Extruder motor	45kw2,55kw4
Reducer	ZLYJ-2502, 2804	Best quality brand in china ,long life and low noise
crew heating power	4kw*24
Plasticizing capacity	700kg/h
die head
Accumulator capacity	60kg	designed by ourselves and get the patent
Die diameter	According to products
Die head heating power	140kw

Automatic 8-Layer 3000L Water Tank Blow Moulding Machine

Product Tags:

automatic 8-layer water tank machine

3000L blow moulding machine

water tank blow moulding machine with warranty

Automatic 8-Layer 3000L Water Tank Blow Moulding Machine Images
